CORE BARRELS — TYPE 01
Core Barrel with Round Shank Chisel
Single-wall core barrel for general-purpose coring in soil and soft to medium rock formations. Open-top design enables easy core sample extraction. Flat cutting teeth provide clean, efficient penetration in non-abrasive ground conditions.
DIAMETER RANGE
600 – 2500 mm
MAX ROCK STRENGTH
≤ 40 MPa
WALL DESIGN
Single-wall
TEETH TYPE
Flat cutting teeth
BODY MATERIAL
Q355 / Hardox 400
KELLY BOX
Universal interchangeable
Product Overview
The ALVRIQ Core Barrel with Round Shank Chisel is designed for general-purpose coring operations in soil, clay, and soft to medium rock formations. Its single-wall construction provides a straightforward, cost-effective solution for extracting cylindrical core samples during geotechnical investigations and foundation drilling.
The barrel body is fabricated from Q355 structural steel with Hardox 400 wear protection on the cutting edge. Flat cutting teeth are arranged in a radial pattern to provide clean, even penetration — producing intact core samples suitable for laboratory analysis.
An open-top configuration allows for easy sample extraction after each coring cycle. The universal kelly box connection (interchangeable with SANY, Zoomlion, XCMG, and BAUER rotary drilling rigs) ensures broad compatibility without modification.
At a Glance
Key Features
Single-Wall Construction
Single-wall barrel body in Q355 steel provides a lightweight, cost-effective solution for general coring. Simplified design reduces maintenance and operating costs.
Radial Flat Teeth
Flat cutting teeth arranged in a radial pattern deliver clean, even cuts in soil and soft rock. Teeth are replaceable and interchangeable for easy field maintenance.
Open-Top Extraction
Open-top barrel design allows core samples to be extracted quickly and easily after each coring cycle. Reduces downtime between sampling operations.
Universal Kelly Box
Interchangeable kelly box fits SANY, Zoomlion, XCMG, and BAUER rotary drilling rigs. No adapter needed — simply bolt on and start drilling.
Suitable Ground Conditions
Recommended For
Not Recommended For
Specifications
| Diameter (mm) | Core Length (mm) | Teeth Count | Tooth Type | Wall Type | Weight (kg) |
|---|---|---|---|---|---|
| 600 | 1000 | 8 | Flat cutting | Single | ~120 |
| 800 | 1200 | 10 | Flat cutting | Single | ~190 |
| 1000 | 1200 | 12 | Flat cutting | Single | ~280 |
| 1200 | 1500 | 14 | Flat cutting | Single | ~380 |
| 1500 | 1500 | 16 | Flat cutting | Single | ~550 |
| 2000 | 1500 | 20 | Flat cutting | Single | ~900 |
* Specifications are indicative and may vary by configuration. Custom diameters up to 2500 mm available on request.
Product Gallery
How to Order
Specify Requirements
Tell us your drilling rig model, required core diameter, and target formation. We’ll recommend the optimal barrel configuration and tooth type.
Confirm Quote
Receive a detailed quotation within 24 hours including specifications, lead time, and shipping terms. Confirm and proceed to production.
Production & Delivery
Manufacturing takes 12–20 days depending on specifications. Quality-tested and shipped to your project site worldwide.
