CORE BARRELS — TYPE 03
Core Barrel with Crossing Cutters
Dual-wall design with inner sample tube that isolates core samples from drilling fluid and contamination. Delivers intact, undisturbed samples for geotechnical analysis. Ideal for fractured formations where sample recovery is critical.
DIAMETER RANGE
600 – 2500 mm
MAX ROCK STRENGTH
≤ 60 MPa
WALL DESIGN
Double-wall + inner tube
TEETH TYPE
Carbide + inner tube
BODY MATERIAL
Q355 / Hardox 400
KELLY BOX
Universal interchangeable
Product Overview
The ALVRIQ Core Barrel with Crossing Cutters is engineered for high-quality sample recovery in fractured and mixed formations. Its dual-wall construction features an inner sample tube that isolates the core from drilling fluid, preserving the integrity of the sample for accurate geotechnical laboratory analysis.
The outer barrel houses the carbide cutting teeth and bears the drilling torque, while the inner tube — made from wear-resistant steel — remains stationary during rotation. This design prevents sample erosion and contamination, delivering recovery rates exceeding 90% in formations where standard barrels achieve less than 50%.
A universal kelly box connection (interchangeable with SANY, Zoomlion, XCMG, and BAUER rotary drilling rigs) ensures broad compatibility. The inner tube is removable for quick sample extraction, reducing downtime between coring cycles.
At a Glance
Key Features
Dual-Wall Isolation
Inner sample tube isolates core from drilling fluid and contamination. Outer barrel bears torque while inner tube stays stationary — preserving sample integrity for accurate analysis.
Carbide Cutting Teeth
Tungsten carbide-tipped teeth on the outer barrel cut through fractured rock up to 60 MPa. Self-rotating sockets distribute wear evenly for extended cutting life.
Removable Inner Tube
Inner tube is quickly removable for fast sample extraction after each coring cycle. Reduces downtime between sampling operations and improves field efficiency.
Universal Kelly Box
Interchangeable kelly box fits SANY, Zoomlion, XCMG, and BAUER rotary drilling rigs. No adapter needed — simply bolt on and start drilling.
Suitable Ground Conditions
Recommended For
Not Recommended For
Specifications
| Diameter (mm) | Core Length (mm) | Teeth Count | Tooth Type | Wall Type | Weight (kg) |
|---|---|---|---|---|---|
| 600 | 1000 | 10 | Carbide tipped | Double-wall | ~180 |
| 800 | 1200 | 12 | Carbide tipped | Double-wall | ~270 |
| 1000 | 1200 | 14 | Carbide tipped | Double-wall | ~390 |
| 1200 | 1500 | 16 | Carbide tipped | Double-wall | ~530 |
| 1500 | 1500 | 20 | Carbide tipped | Double-wall | ~780 |
| 2000 | 1500 | 24 | Carbide tipped | Double-wall | ~1,200 |
* Specifications are indicative and may vary by configuration. Custom diameters up to 2500 mm available on request.
Product Gallery
How to Order
Specify Requirements
Tell us your drilling rig model, required core diameter, and formation characteristics. We’ll recommend the optimal dual-wall configuration and inner tube specification.
Confirm Quote
Receive a detailed quotation within 24 hours including specifications, lead time, and shipping terms. Confirm and proceed to production.
Production & Delivery
Manufacturing takes 18–28 days depending on specifications. Quality-tested and shipped to your project site worldwide.
